Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR

China Yingxinyuan Int'l(Group) Ltd. certification
China Yingxinyuan Int'l(Group) Ltd. certification
I'm Online Chat Now

Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR

Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR
Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR

Large Image :  Through Hole Mount Power Amplifier ICs 145MHz 700nA THS4521IDR

Product Details:
Place of Origin: N/S
Brand Name: Texas Instruments
Certification: /
Model Number: THS4521IDR
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Delivery Time: 2-7 work days
Payment Terms: T/T
Supply Ability: 9999999+PCS
Detailed Product Description
Warranty: 90days After Shipping Application: Automotive Industrial Automation Enterprise And Mobile Consumer
Shipping By: DHLUPSFedexEMSTNTAramex Mounting Type: Through Hole
Packaging: Trade Assurance/TT/Paypal/Western Union
High Light:

145MHz Power Amplifier ICs

,

Through Hole Mount Power Amplifier ICs

,

THS4521IDR

Amplifier IC Chips Texas Instruments/TI THS4521IDR

ECAD Module PCB Symbol,Footprint & 3D Model
Supply and Demand Status Limited
Fake Threat In the Open Market 52 pct.
Popularity High
Is this a common-used part? Yes
Case / Package 8-SOIC
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 85°C
Supply Voltage - Operating 2.5 V to 5.5 V, ±1.25 V to 2.75 V
Channel Output Current 55mA
-3db Bandwidth 145MHz
Current - Input Bias 700nA
Voltage - Input Offset 240μV
Output Type Differential, Rail-to-Rail
Number of Circuits 1
Operating Supply Current 1.14mA
Status Active
Packaging Reel - TR
Manufacturer Texas Instruments
Categories Integrated Circuits
Gain Bandwidth Product (GBP) 95MHz
Slew Rate 600 V/μs
Amplifier Type Differential



Features for the THS4521

  • Fully Differential Architecture
  • Bandwidth: 145 MHz (AV = 1 V/V)
  • Slew Rate: 490 V/µs
  • HD2: –133 dBc at 10 kHz (1 VRMS,
    RL = 1 kΩ)
  • HD3: –141 dBc at 10 kHz (1 VRMS,
    RL = 1 kΩ)
  • Input Voltage Noise: 4.6 nV/√Hz
    (f = 100 kHz)
  • THD+N: –112dBc (0.00025%) at
    1 kHz (22-kHz BW, G = 1, 5 VPP)
  • Open-Loop Gain: 119 dB (DC)
  • NRI–Negative Rail Input
  • RRO–Rail-to-Rail Output
  • Output Common-Mode Control
    (with Low Offset)
  • Power Supply:
    • Voltage: +2.5 V (±1.25 V) to
      +5.5 V (±2.75 V)
    • Current: 1.14 mA/ch
  • Power-Down Capability: 20 µA (typical)

Description for the THS4521

The THS4521, THS4522, and THS4524 family of devices are very low-power, fully differential amplifiers with rail-to-rail output and an input common-mode range that includes the negative rail. These amplifiers are designed for low-power data acquisition systems and high-density applications where power dissipation is a critical parameter, and provide exceptional performance in audio applications.

The family includes single FDA (THS4521), dual FDA (THS4522), and quad FDA (THS4524) versions.

These fully differential amplifiers feature accurate output common-mode control that allows for dc-coupling when driving analog-to-digital converters (ADCs). This control, coupled with an input common-mode range below the negative rail as well as rail-to-rail output, allows for easy interfacing between single-ended, ground-referenced signal sources. Additionally, these devices are ideally suited for driving both successive-approximation register (SAR) and delta-sigma (ΔΣ) ADCs using only a single +2.5V to +5V and ground power supply.

The THS4521, THS4522, and THS4524 family of fully differential amplifiers is characterized for operation over the full industrial temperature range from –40°C to +85°C.
