50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments

50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments
50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments 50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments 50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments 50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments 50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments

Large Image :  50Hz Powerline Fault Indicators IEC60439 TLVH431AQDBZT Texas Instruments

Product Details:
Place of Origin: N/S
Brand Name: Texas Instruments
Certification: /
Model Number: TLVH431AQDBZT
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Delivery Time: 2-7 work days
Payment Terms: T/T
Supply Ability: 9999999+PCS
Detailed Product Description
Product Name: Fault Indicator Type: Power Distribution System
Lead Time For Sample: Within 5 Days Rated Frequency: 50Hz/60Hz
Standard: IEC60439
High Light:

IEC60439 Powerline Fault Indicators

,

50Hz Powerline Fault Indicators

,

TLVH431AQDBZT

Power Line Inductor Texas Instruments TLVH431AQDBZT

ECAD Module PCB Symbol,Footprint & 3D Model
Supply and Demand Status Balance
Fake Threat In the Open Market 55 pct.
Popularity Medium
Win Source Part Number 1109796-TLVH431AQDBZT
Case / Package SOT-23-3
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 125°C (TA)
Maximum Output Voltage 18V
Nominal Output Voltage (Min/Fixed) 1.24V
Output Type Adjustable
Reference Type Shunt
Status Active
Packaging Reel - TR
Manufacturer Texas Instruments
Categories Integrated Circuits
Output Current 70mA
Tolerance ±1%
Current - Cathode 100μA



Features for the TLVH431A

  • Low-Voltage Operation: Down to 1.24 V
  • Reference Voltage Tolerances at 25°C
    • 0.5% for B Grade
    • 1% for A Grade
    • 1.5% for Standard Grade
  • Adjustable Output Voltage, VO = VREF to 18 V
  • Wide Operating Cathode Current Range: 100 µA to 70 mA
  • 0.25-Ω Typical Output Impedance
  • –40°C to +125°C Specifications
  • TLVH432 Provides Alternative Pinouts for SOT-23-3 and SOT-89 Packages
  • Ultra-Small SC-70 Package Offers 40% Smaller Footprint than SOT-23-3

Description for the TLVH431A

The TLVH431 and TLVH432 devices are low-voltage 3-terminal adjustable voltage references, with specified thermal stability over applicable industrial and commercial temperature ranges. Output voltage can be set to any value between VREF (1.24 V) and 18 V with two external resistors (see ). These devices operate from a lower voltage (1.24 V) than the widely used TL431 and TL1431 shunt-regulator references.

When used with an optocoupler, the TLVH431 and TLVH432 devices are ideal voltage references in isolated feedback circuits for 3-V to 3.3-V switching-mode power supplies. They have a typical output impedance of 0.25 Ω. Active output circuitry provides a very sharp turn-on characteristic, making the TLVH431 and TLVH432 devices excellent replacements for low-voltage Zener diodes in many applications, including on-board regulation and adjustable power supplies.

The TLVH432 device is identical to the TLVH431 device, but is offered with different pinouts for the 3-pin SOT-23 and SOT-89 packages.
