| Type: | Power Distribution System | Lead Time For Sample: | Within 5 Days |
|---|---|---|---|
| Standard: | IEC60439 | Applicable Wire Diameter: | 16mm Sq≤D≤240mm Sq |
| Applicable Voltage Range: | 6~35KV | ||
| High Light: | 35KV Powerline Fault Indicators,Texas Instruments Powerline Fault Indicators,TPS63002DRCR |
||
| ECAD Module | PCB Symbol,Footprint & 3D Model |
| ECCN | EAR99 |
| Country of Origin | Malaysia, Philippines |
| Halogen Free | Compliant |
| Estimated EOL Date | 2031 |
| Alternative Parts (Cross-Reference) |
ADP2504ACPZ-4.2-R7; ADP2503ACPZ-5.0-R7; ADP2504ACPZ-4.5-R7; ADP2503ACPZ-4.5-R7; |
| Supply and Demand Status | Sufficient |
| Fake Threat In the Open Market | 28 pct. |
| Popularity | High |
| Is this a common-used part? | Yes |
| Case / Package | 10-VSON (3x3) |
| Mounting | SMD (SMT) |
| Temperature Range - Operating | -40°C to 85°C (TA) |
| Synchronous Rectifier | Yes |
| Win Source Part Number | 034418-TPS63002DRCR |
| Family Name | TPS63002 |
| Nominal Output Voltage (Min/Fixed) | 5V |
| Maximum Input Voltage | 5.5V |
| Minimum Input Voltage | 1.8V |
| Number of Outputs | 1 |
| Output Type | Fixed |
| Introduction Date | July 05, 2005 |
| Frequency - Switching | 1.25MHz to 1.5MHz |
| Status | Active |
| Packaging | Reel - TR |
| Manufacturer | Texas Instruments |
| Categories | Integrated Circuits |
| Output Current | 1.6A (Switch) |
| Topology | Buck-Boost |
| Purpose | Step-Up/Step-Down |
All trademarks are the property of their respective owners.
The TPS6300x devices provide a power supply solution for products powered by either a two-cell or three-cell alkaline, NiCd or NiMH battery, or a one-cell Li-ion or Li-polymer battery. Output currents can go as high as 1200 mA while using a single-cell Li-ion or Li-polymer battery, and discharge it down to 2.5 V or lower. The buck-boost converter is based on a fixed frequency, pulse width modulation (PWM) controller using synchronous rectification to obtain maximum efficiency. At low load currents, the converter enters power-save mode to maintain high efficiency over a wide load current range. The power-save mode can be disabled, forcing the converter to operate at a fixed switching frequency. The maximum average current in the switches is limited to a typical value of 1800 mA. The output voltage is programmable using an external resistor divider, or is fixed internally on the chip. The converter can be disabled to minimize battery drain. During shutdown, the load is disconnected from the battery.
The TPS6300x devices operate over a free air temperature range of –40°C to 85°C. The devices are packaged in a 10-pin VSON package (QFN) measuring 3 mm × 3 mm (DRC).
