4A Power Line Inductor TI TPS259533DSGT Power Management ICs

China Yingxinyuan Int'l(Group) Ltd. certification
China Yingxinyuan Int'l(Group) Ltd. certification
I'm Online Chat Now

4A Power Line Inductor TI TPS259533DSGT Power Management ICs

4A Power Line Inductor TI TPS259533DSGT Power Management ICs
4A Power Line Inductor TI TPS259533DSGT Power Management ICs 4A Power Line Inductor TI TPS259533DSGT Power Management ICs 4A Power Line Inductor TI TPS259533DSGT Power Management ICs 4A Power Line Inductor TI TPS259533DSGT Power Management ICs

Large Image :  4A Power Line Inductor TI TPS259533DSGT Power Management ICs

Product Details:
Place of Origin: N/S
Brand Name: Texas Instruments
Certification: /
Model Number: TPS259533DSGT
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Delivery Time: 2-7 work days
Payment Terms: T/T
Supply Ability: 9999999+PCS
Detailed Product Description
Product Name: Overhead Line Fault Location Monitoring System Type: Power Distribution System
Lead Time For Sample: Within 15 Days Mtbf: More Than 70000H
Joint Type: Clamp Joint Type
High Light:

TPS259533DSGT Power Line Inductor

,

4A Power Line Inductor

,

TI Power Management ICs

Power Line Inductor Texas Instruments/TI TPS259533DSGT

Product Properties Attribute Value
Manufacturer: Texas Instruments
Product Category: Hot swap voltage controller
Product: PCI Power Management
Current Limit: 4A
Number of Channels: 1 Channel
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Installation Style: SMD/SMT
Package / Case: WSON-8
Package: Reel
Package: Cut Tape
Package: MouseReel
Power Failure Detection: No
Trademark: Texas Instruments
Input/Supply Voltage - Maximum: 18 V
Input/Supply Voltage - Min: 2.7 V
Moisture Sensitivity: Yes
product Type: Hot Swap Voltage Controllers
Series: TPS2595
Subcategory: PMIC - Power Management ICs
unit weight: 12 mg



Features for the TPS2595

  • Wide Input Voltage Range: 2.7 V to 18 V
    • 20 V Absolute Maximum
    • 3 V to 18 V for TPS2595x5 Version
  • Low On-Resistance: RON = 34 mΩ (Typical)
  • Fast Overvoltage Protection Clamp (3.8-V, 5.7-V, and 13.7-V options) With a Response Time of 5 µs (Typical)
  • TPS2595x0, TPS2595x1, TPS2595x5: Active High Enable Input With Adjustable Undervoltage Lockout (UVLO)
  • TPS2595x3: Active Low Enable Input With Adjustable Overvoltage Lockout (OVLO)
  • Adjustable Current Limit With Load Current Monitor Output (ILM)
    • Current Range: 0.5 A to 4 A
    • Current Limit Accuracy: ±7.5%
  • Adjustable Output Slew Rate Control (dVdt)
  • Over Temperature Protection (OTP)
  • Fault Indication Pin (FLT )
  • UL 2367 Recognition – File No. E169910
    • RILM >= 487 Ω (4.42 A maximum)
  • IEC 62368-1 Certified
  • Safe During Single Point Failure Test (IEC 62368-1)
    • ILM Pin Open/Short Detection

Description for the TPS2595

The TPS2595xx family of eFuses (integrated FET hot swap devices) is a highly integratedcircuit protection and power management solution in a small package. The devices provide multipleprotection modes using very few external components and are a robust defense against overloads,short circuits, voltage surges, and excessive inrush current.

Output current limit level can be set with a single external resistor. It is alsopossible to get an accurate sense of the output load current by measuring the voltage drop acrossthe current limit resistor. Applications with particular inrush current requirements can set theoutput slew rate with a single external capacitor. Overvoltage events are quickly limited byinternal clamping circuits to a safe fixed maximum, with no external components required. TheTPS259573 variant provides an option to set a user-defined overvoltage cutoff threshold.

Quick output discharge function can be implemented in the TPS2595x5 variants byconnecting the OUT pin to the QOD pin.

The devices are characterized for operation over the temperature range of –40°C to+125°C.
