3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR

China Yingxinyuan Int'l(Group) Ltd. certification
China Yingxinyuan Int'l(Group) Ltd. certification
I'm Online Chat Now

3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR

3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR
3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR 3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR 3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR 3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR

Large Image :  3000MHz Original IC Electronic Components Texas Instruments TMUX1511RSVR

Product Details:
Place of Origin: N/S
Brand Name: Texas Instruments
Certification: /
Model Number: TMUX1511RSVR
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Delivery Time: 2-7 work days
Payment Terms: T/T
Supply Ability: 9999999+PCS
Detailed Product Description
Type: Logic ICs Package: Standard Package (plastic Bag/carton Box)
Condition: Brand New And Original Packaging: Tube Tray Tape Reel Bag
Application: Electronic Componets
High Light:

Original IC Electronic Components

,

3000MHz IC Electronic Components

,

TMUX1511RSVR

IC Electronic Components Texas Instruments/TI TMUX1511RSVR

Configuration 1:1 SPST
Number of channels (#) 4
Power supply voltage - single (V) 1.8, 2.5, 3.3, 5
Protocols Analog, JTAG, UART, I2C, SPI, RGMII, TDM, I2S
Ron (Typ) (Ohms) 2
CON (Typ) (pF) 3.3
ON-state leakage current (Max) (µA) 0.05
Bandwidth (MHz) 3000
Operating temperature range (C) -40 to 125
Features 1.8-V compatible control inputs, Fail-safe logic, Integrated pulldown resistor on logic pin, Powered-off protection, Supports input voltage beyond supply
Input/output continuous current (Max) (mA) 25
Rating Catalog
Supply current (Typ) (uA) 37



Features for the TMUX1511

  • Wide Supply Range: 1.5 V to 5.5 V
  • Low On-Capacitance: 3.3 pF
  • Low On-Resistance: 2 Ω
  • High Bandwidth: 3 GHz
  • -40°C to +125°C Operating Temperature
  • 1.8 V Logic Compatible
  • Supports Input Voltage Beyond Supply
  • Integrated Pull Down Resistor on Logic Pins
  • Bidirectional Signal Path
  • Fail-Safe Logic
  • Powered-off Protection up to 3.6 V
    • Pinout compatible to SN74CBTLV3126
    • Pinout compatible (logic variant) of SN74CBTLV3125

Description for the TMUX1511

The TMUX1511 is a complementary metal-oxide semiconductor (CMOS) switch.The TMUX1511 offers 1:1 SPST switch configuration with 4 independently controlledchannels. Wide operating supply of 1.5 V to 5.5 V allows for use in a broad array of applicationsfrom servers and communication equipment to industrial applications. The device supportsbidirectional analog and digital signals on the source(Sx) and drain (Dx) pins and can pass signals above supply up to VDD x 2,with a maximum input/output voltage of 5.5 V.

Powered-off Protection up to 3.6 V on thesignal path of the TMUX1511 provides isolation when the supply voltage is removed(VDD = 0 V). Without this protection feature, switches can back-power thesupply rail through an internal ESD diode and cause potential damage to the system.

Fail-Safe Logic circuitry allows voltages onthe logic control pins to be applied before the supply pin, protecting the device from potentialdamage. All logic control inputs have1.8 V logic compatible thresholds, ensuring both TTL andCMOS logic compatibility when operating in the valid supply voltage range.
