2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS

China Yingxinyuan Int'l(Group) Ltd. certification
China Yingxinyuan Int'l(Group) Ltd. certification
I'm Online Chat Now

2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS

2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS
2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS 2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS 2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS 2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS 2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS

Large Image :  2.2UF SMD Chip Capacitor TPS54360BQDDARQ1 Lead Free 8542.39.0001 HTSUS

Product Details:
Place of Origin: N/S
Brand Name: Texas Instruments
Certification: /
Model Number: TPS54360BQDDARQ1
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Delivery Time: 2-7 work days
Payment Terms: T/T
Supply Ability: 9999999+PCS
Detailed Product Description
Capacitance: 2.2UF Package Type: Through Hole
Date Code: The Lasteds Code Quality: 100% Brand
Lead Free Status: NOPB
High Light:

2.2UF SMD Chip Capacitor

,

Lead Free SMD Chip Capacitor

,

TPS54360BQDDARQ1

SMD Chip Capacitor Texas Instruments/TI TPS54360BQDDARQ1

ECAD Module PCB Symbol,Footprint & 3D Model
Supply and Demand Status Limited
Popularity Medium
Fake Threat In the Open Market 32 pct.
Quantity per package 2500
HTSUS 8542.39.0001
ECCN EAR99
REACH Status REACH Unaffected
MSL Level 2 (1 Year)
Family Name TPS54360
Package Reel - TR
Series Automotive, AEC-Q100, Eco-Mode™
Manufacturer Texas Instruments
Features Switching Regulator IC Output
Estimated Pruduction Lead Time 34 Weeks
Categories Integrated Circuits (ICs)
Other Part Number 296-TPS54360BQDDARQ1TR, 296-TPS54360BQDDARQ1DKR, 296-TPS54360BQDDARQ1CT, 296-46985-1, 296-46985-2, 296-46985-6-ND, 296-46985-2-ND, -296-46985-1-ND, 296-46985-1-ND, 296-46985-6



Features for the TPS54360B-Q1

  • Qualified for Automotive Applications
  • AEC-Q100 Qualified With the Following Results:
    • Device Temperature Grade 1: –40°C to 125°C Ambient Operating Temperature Range
    • Device HBM ESD Classification Level H1C
    • Device CDM ESD Classification Level C3B
  • High Efficiency at Light Loads With Pulse Skipping Eco-Mode™
  • 92-mΩ High-Side MOSFET
  • 146-µA Operating Quiescent Current and 2 µA Shutdown Current
  • 100-kHz to 2.5-MHz Adjustable Switching Frequency
  • Synchronizes to External Clock
  • Low Dropout at Light Loads With Integrated BOOT Recharge FET
  • Adjustable UVLO Voltage and Hysteresis
  • 0.8-V 1% Internal Voltage Reference
  • 8-Pin HSOP With PowerPAD™ Package
  • –40°C to 150°C TJ Operating Range

Description for the TPS54360B-Q1

The TPS54360B-Q1 is a 60-V 3.5-A step-down regulator with an integrated high-side MOSFET. The device survives load dump pulses up to 65 V per ISO 7637. Current mode control provides simple external compensation and flexible component selection. A low-ripple pulse-skip mode reduces the no-load supply current to 146 µA. Shutdown supply current is reduced to 2 µA when the enable pin is pulled low.

Undervoltage lockout is internally set at 4.3 V but can be increased using an external resistor divider at the enable pin. The output voltage start-up ramp is internally controlled to provide a controlled start up and eliminate overshoot.

A wide adjustable frequency range allows either efficiency or external component size to be optimized. Frequency foldback and thermal shutdown protects internal and external components during an overload condition.

The TPS54360B-Q1 is available in an 8-pin thermally enhanced HSOP PowerPAD package.



Contact Details
Yingxinyuan Int'l(Group) Ltd.

Contact Person: sales

Tel: 0755-8324-7000

Send your inquiry directly to us (0 / 3000)
