Product Details:
Payment & Shipping Terms:
|
Package: | Standard Package (plastic Bag/carton Box) | Lead Free Status: | RoHS Complia |
---|---|---|---|
Warranty: | 90days After Shipping | Material: | Brass |
Skype: | Julixin002 | ||
High Light: | MDIO I2C IC Chip,8 Bits I2C IC Chip,TXS0108ENMER |
IC Electronic Components Texas Instruments/TI TXS0108ENMER
Technology Family | TXS |
Applications | I2C, MDIO, SMbus |
Bits (#) | 8 |
High input voltage (Min) (Vih) | 1 |
High input voltage (Max) (Vih) | 5.5 |
Vout (Min) (V) | 1.4 |
Vout (Max) (V) | 5.5 |
IOH (Max) (mA) | 0 |
IOL (Max) (mA) | 0 |
Rating | Catalog |
This device is an 8-bit non-inverting level translator that uses two separateconfigurable power-supply rails. The A port tracks the VCCA pin supplyvoltage. The VCCA pin accepts any supply voltage between1.4 V and 3.6 V. The B port tracksthe VCCB pin supply voltage. The VCCB pin accepts anysupply voltage between 1.65 V and 5.5 V. Two input supply pins allows for low Voltage bidirectionaltranslation between any of the 1.5 V, 1.8 V, 2.5 V, 3.3 V, and 5 V voltage nodes.
When the output-enable (OE) input is low, all outputs are placed in the high-impedance(Hi-Z) state.
To ensure the Hi-Z state during power-up or power-down periods, tie OE to GND through apull-down resistor. The minimum value of the resistor is determined by the current-sourcingcapability of the driver.
