Components Electronic Integrated Circuits MCF CC430F5147IRGZR

Components Electronic Integrated Circuits MCF CC430F5147IRGZR
Components Electronic Integrated Circuits MCF CC430F5147IRGZR Components Electronic Integrated Circuits MCF CC430F5147IRGZR Components Electronic Integrated Circuits MCF CC430F5147IRGZR Components Electronic Integrated Circuits MCF CC430F5147IRGZR Components Electronic Integrated Circuits MCF CC430F5147IRGZR

Large Image :  Components Electronic Integrated Circuits MCF CC430F5147IRGZR

Product Details:
Place of Origin: N/S
Brand Name: Texas Instruments
Certification: /
Model Number: CC430F5147IRGZR
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotiation
Delivery Time: 2-7 work days
Payment Terms: T/T
Supply Ability: 9999999+PCS
Detailed Product Description
Type: TxRx + MCU RF Family/Standard: General ISM
Modulation: 2FSK, 2GFSK, ASK, MSK, OOK Frequency: 300MHz ~ 348MHz, 389MHz ~ 464MHz, 779MHz ~ 928MHz
Serial Interfaces: I2C, IrDA, JTAG, SPI, UART Memory Size: 32kB Flash, 4kB SRAM
High Light:

300MHz Electronic Integrated Circuits

,

MCF Electronic Integrated Circuits

,

2FSK Electronic IC Chip

Electronic Components Integrated Circuits MCF CC430F5147IRGZR

Manufacturer Texas Instruments
Packaging Reel
Type TxRx + MCU
RF Family/Standard General ISM
Modulation 2FSK, 2GFSK, ASK, MSK, OOK
Frequency 300MHz ~ 348MHz, 389MHz ~ 464MHz, 779MHz ~ 928MHz
Data Rate (Maximum) 500kBaud
Power - Output 13dBm
Sensitivity -117dBm
Memory Size 32kB Flash, 4kB SRAM
Serial Interfaces I2C, IrDA, JTAG, SPI, UART
GPIO 30
Supply Voltage (V) 2V ~ 3.6V
Current - Receiving 15mA ~ 18.5mA
Current - Transmitting 15mA ~ 36mA
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Manufacturer Package 48-VFQFN Exposed Pad
Supplier Device Package 48-VQFN (7x7)
Manufacturer Pack Quantity 2,500
MSL Level 3 (168 Hours)
Popularity Medium
Fake Threat In the Open Market 33 pct.
Supply and Demand Status Balance



Features



• True System-on-Chip (SoC) for Low-Power Wireless Communication Applications

• Wide Supply Voltage Range: 3.6 V Down to 1.8 V

• Ultra-Low Power Consumption:

– CPU Active Mode (AM): 160 µA/MHz

– Standby Mode (LPM3 RTC Mode): 2.0 µA

– Off Mode (LPM4 RAM Retention): 1.0 µA

– Real-Time Clock (RTC) Only Mode (LPM3.5): 1.0 µA

– Shutdown Mode (LPM4.5): 0.3 µA

– Radio in RX: 15 mA, 250 kbps, 915 MHz

• MSP430™ System and Peripherals

– 16-Bit RISC Architecture, Extended Memory, up to 20-MHz System Clock

– Wake up From Standby Mode in Less Than 6 µs

– Flexible Power-Management System With SVS and Brownout

– Unified Clock System With FLL

– 16-Bit Timer TA0, Timer_A With Five Capture/Compare Registers

– 16-Bit Timer TA1, Timer_A With Three Capture/Compare Registers

– Hardware RTC

– Two Universal Serial Communication Interfaces (USCIs)

– USCI_A0 Supports UART, IrDA, SPI – USCI_B0 Supports I 2C, SPI

– 10-Bit Analog-to-Digital Converter (ADC) With Internal Reference, Sample-and-Hold, and Autoscan Features (Only CC430F614x and CC430F514x)

– Comparator

– Integrated LCD Driver With Contrast Control for up to 96 Segments (Only CC430F614x)

– 128-Bit AES Security Encryption and Decryption Coprocessor

– 32-Bit Hardware Multiplier

– 3-Channel Internal DMA

– Serial Onboard Programming, No External Programming Voltage Needed

– Embedded Emulation Module (EEM)

• High-Performance Sub-1 GHz RF Transceiver Core

– Same as in CC1101

– Wide Supply Voltage Range: 2 V to 3.6 V

– Frequency Bands: 300 MHz to 348 MHz, 389 MHz to 464 MHz, and 779 MHz to 928 MHz

– Programmable Data Rate From 0.6 kBaud to 500 kBaud

– High Sensitivity (–117 dBm at 0.6 kBaud, –111 dBm at 1.2 kBaud, 315 MHz, 1% Packet Error Rate)

– Excellent Receiver Selectivity and Blocking Performance

– Programmable Output Power up to +12 dBm for All Supported Frequencies

– 2-FSK, 2-GFSK, and MSK Supported, Also OOK and Flexible ASK Shaping

– Flexible Support for Packet-Oriented Systems: On-Chip Support for Sync Word Detection, Address Check, Flexible Packet Length, and Automatic CRC Handling

– Support for Automatic Clear Channel Assessment (CCA) Before Transmitting (for Listen-Before-Talk Systems)

– Digital RSSI Output

– Suited for Systems Targeting Compliance With EN 300 220 (Europe) and FCC CFR Part 15 (US)

– Suited for Systems Targeting Compliance With Wireless M-Bus Standard EN 13757‑4:2005

– Support for Asynchronous and Synchronous Serial Receive/Transmit Mode for Backward Compatibility With Existing Radio Communication Protocols

• Device Comparison Summarizes the Available Family Members



 Applications



• Wireless Analog and Digital Sensor Systems

• Heat Cost Allocators

• Thermostats

• AMR and AMI Meters

• Smart Grid Wireless Networks
